Introducing Next Generation WCE Series

WCE product photo.png
hr logo.png

REQUEST A QUOTE

Success! Message received.


High Resolution 100㎛

WCE-HR represents a premium solution tailored for high-resolution diagnostic needs with 100㎛ pixel pitch. Its remarkable capability to capture images with unparalleled clarity and precision makes it an indispensable tool for medical professionals specializing in extremity diagnosis. It ensures that even the tiniest details are vividly portrayed, facilitating accurate diagnosis of microscopic areas such as fractures.

HR 100.gif

Meet the next generation of X-ray automatic exposure detection with our AcuDetect technology. Our state-of-the-art silicon-based sensors are designed to detect individual photons, ensuring accurate and dependable identification of X-rays that have been exposed. Detectors equipped with AcuDetect reliably recognize X-ray doses, even for patients weighing nearly 300 pounds or low dose levels.

acudetect img.png

Until now, a choice had to be made between a 140μm and 100μm digital X-ray detector depending on the specific application and requirements of the site. However with the new MultiPixel technology, you can take advantage of both pixel pitch by switching modes on demand!

icons 1.png
icons 2.png

16 Hours Battery Life

Best in class 16 hour dual batteries offer the convenience of hot-swapping for uninterrupted usage. 10min charge from 0% provides a substantial 40 minutes of operational time.

Lightweight

Slip & Impact Protection

The portable detector allows for more precise movement and enhances security during interactions with the detector.

Integrating aerospace grade slip prevention and bumper system to prevent and protect against impact damage, provide tackiness to prevent slip, and is resistant against corrosive elements.

IP 67 Water & Dust Resistance

Enhanced Resistance prevents liquid penetration and is designed to shield against dust and contaminants.


Specifications

​

Sensor Type
Scintillator Type
Pixel Pitch (μm)
AcuDetect
MultiPixel
Glass Free
Battery Operating Time (hrs)
Weight (w/out battery)
Data Transfer


Energy Range (kVp)
A/D Conversion (bits)
Total Pixel Matrix (Pixels)
Dimension (mm)

​

​

  a-si TFT
Direct Deposit CsI
100
Yes
Yes
-
Max 16
5.2 lbs
GigE
802.11a/g/n/ac
40 - 150
16
3534 x 4302
384 x 460 x 15

* Specifications subject to change without prior notice *
