RADIOGRAPHY

SOLUTIONS

Urgent Care

In the urgent care market, flexibility and speed are critical. Rayence offers a full line of X-ray equipment to meet the need of this market. Ranging from the cost-effective XR-5L to the innovative flexible Flex-Rad system, we have a solution to meet any requirement.

If a new x-ray room is not needed but throughput improvement is still the goal, Rayence has both tethered as well as wireless DR systems that can be easily added to any existing x-ray room in a matter of hours. All of our DR systems feature a full complement of DICOM protocols as well as software for in exam room viewing as well as burning of CDs.

Urgent Care

Menu

DR Flat Panel Detectors

GreenON 1417

1417WCC/WGC

1717SCC/SGC

Universal Radiography Systems

GOXR-L

GOXR

Flex-Rad

Software



Xmaru View V1


GreenONLogo.tif

1417

14x17 Wireless Flat Panel Detector


Rayence innovations in manufacturing have allowed us to create a new generation of Low Dose Cesium Iodide wireless detectors to meet the needs of all applications with superior image quality at a substantially lower dose

Powered by


Improved Sensitivity

Normal Version

GreenONLogo.tif

Lower Dose

Low Dose Chart.png

Specifications

Active Area
Scintillator
Resolution
Effective Pixel Matrix
Pixel Pitch
A/D Conversion
Preview Time
Operation Environment




Energy Range
Data Output
Weight
Dimensions

  16.8 x 13.8 inch
Cesium
  3.5 lp/mm
   2500 x 3052
  140 ㎛
14/16 bit
  ≤ 5 Sec.
Temperature. +5 ~ +40°F
Humidity. 30 ~ 75%
Pressure. 70 ~ 106 kPa
  40~150 kVp
  Ethernet 1 Gbps Ethernet
  6.6 lbs / 3 kg
18.1 x 15.1 x 0.6 in

* Specifications subject to change without prior notice *



1417WCC

14x17 Wireless DR Flat Panel Detector

1417WCC

PROVIDING PATIENT THROUGHPUT IN YOUR HOSPITAL AND BEYOND

The ergonomically designed C-Series Cesium Iodide and Gadolinium Oxysulfide wireless detectors are designed to offer new levels of handling, functionality and exceptional diagnostic image quality in the X-ray room and beyond.

The compact and lightweight Xmaru 1417 Wireless Digital Flat Panel Detectors are well designed to satisfy the daily diagnostic needs of the most demanding user.

DICOM File Management and Printing
Image Magnification
Image Stitching

CD recording with CD viewer
Measuring the Length and Angles of the Image
Adding Annotation Text, Graphics and Electronic Markers to an Image

1417WCC

Superb Image Quality

The detector's high Detector Quantum Efficiency (DQE) achieves superb image quality with low patient dose.

Durability

Supporting up to 660 lbs, the detector is manufactured with a shock, vibration, and scratch-resistant carbon fiber composition.

Water Resistant (IP 66)

The detector is water-resistant to most typical water spills in a hospital as well as in outdoor applicants.

Specifications

Active Area
Scintillator
Resolution
Effective Pixel Matrix
Pixel Pitch
A/D Conversion
Preview Time
Operation Environment




Energy Range
Data Output
Weight
Dimensions

  16.8 x 13.8 inch
Cesium
  3.5 lp/mm
   2500 x 3052
  140 ㎛
14/16 bit
  ≤ 5 Sec.
Temperature. +5 ~ +40°F
Humidity. 30 ~ 75%
Pressure. 70 ~ 106 kPa
  40~150 kVp
  Ethernet 1 Gbps Ethernet
  6.6 lbs / 3 kg
18.1 x 15.1 x 0.6 in

* Specifications subject to change without prior notice *



1717SCC

17x17 Tethered Flat Panel Detector

UNIVERSAL AND AFFORDABLE SOLUTION WITH LARGE COVERAGE

The 1717SCC is designed to provide a larger imaging area while eliminating the need to rotate the detector to capture even the widest chest or abdomen.

The detector possesses the thickness of traditional ISO 4090 film cassettes, which makes retrofitting them into standard cassette trays easy. The use of 17x17 inch detector provides more flexibility when positioning anatomy and eliminates the need to be rotated for certain.

The 1717 S-Series is constructed with Rayence's auto-trigger signal sensing technology, removing the need for generator integration. Efficiency is improved by streamlining workflow through the elimination of the additional steps required when using film or CR.

Together with an image preview time of less than 5 seconds, patient throughput and overall productivity is increased, and the wait time for patients is decreased, providing an economical and ideal solution for any X-ray room.

1717SCC

Auto-Trigger Signal Sensing Technology
17x17 inch Active Area
Ideal for Table and Upright Wall Stands

Lightweight and Thin Dimensions
Ideal CR Cassette Repalcement.
140㎛ Pixel Pitch

Specifications

Detection Area
Sensor Type
Scintillator
Pixel Matrix
Pixel Pitch
A/D Conversion
Resolution
Preview Time
Energy Range
Data Output
Weight
Dimensions

 17 x 17 inch
Amorphous Silicon with TFT
  Cesium
3072 x 3072
140㎛
14/16 bit
Max. 3.5lp/mm
  ≤ 2Sec.
  40~150kVp
   Ethernet 1Gbps
9.25lbs / 4.2kg
18.1 x 18.1 x 0.6in

* Specifications subject to change without prior notice *



Fully Integrated Wall/Ceiling Mounted X-ray Room

XR5L

Economical Full-Featured Radiographic Room

The GOXR-L is a full-featured radiographic room that comes standard with the Rayence’s 1417WCC or upgraded to premium with the NEW low dose GreenON DR system which is fully integrated with the generator controls and all DR and generator functions can be controlled from the large touch screen workstation display with the Xmaru V1 software.

Fully Integrated
Compact Design

Recessed Foot-Pedals

Wall Stand Lowers to Below 10”

4 Way Table (6 way elevating table optional)

Ability to
configure the system with either a compact 4 way
floating top or optional 6 way elevating top table.

The long vertical travel of both
the wall stand and tube arm
facilitate a full range of exams

The single large
foot pedal release
simplifies
movement and
locking of tabletop

Crosstable exams
are easily
performed using
the +/- 180 degree
rotational and +/- 5”
transverse positioning capability

Specifications

DETECTOR

Model



TUBE STAND

Style
Rail length
Transverse travel
Long Travel of Focal Spot
Display

Vertical Travel Range


Wall to focal spot at detent position
Tube Rotation

WALL STAND

Model
Vertical Travel Range
Left or Right Hand Load Bucky



TUBE

Model
Tube Focal Spot



COLLIMATOR

Model
Style
Features

GENERATOR

Generator Power Output
mA range
Power
mAs range



TABLE

Model
Movement
Vertical travel
Transverse/Long Travel
Dimensions
Grid

OPTION

Option
Table travel
Transverse travel
Longitudinal travel
Weight Capacity



ROOM

Min. Required

1417WCC / GreenON 1417(Premium)



floor to wall or ceiling
8 ft rail or 10 ft rail
plus / minus 5" travel
75.7" w/ 8ft rail, 99.7" w/ 10ft rail
angulation dial, handgrips, electric locks
76.8" max, 76.4-76.9 trunnion,

13.5 beam horizontal
39.2" platform, 40.3" trunnion ring
180 degrees 90 degrees detents



S109
9.75" - 72.75"
yes



E411
.6-1.5 focal, 200 KHU



5658
LED , 150kVp w/ swivel mount
laser bucky light and tape measure



 421/3e, 42kW high freq
25-500mA
205/250-1 phase 208/408-3 phase
0.1-600mAs



S210
four way float
none
10" transverse, 32" longitudinal
84"x30.5", table height 31.5"
103LP, 10:1



can upgrade to 6 way (S211)
22"-33"
plus or minus 5"
32"
400 lbs



 12'6" x 11' x 9'

* Specifications subject to change without prior notice *



Digital Radiography Table

XR5

Versatile Full Featured Heavy Duty Radiographic Room

The GOXR is a full-featured radiographic room that comes standard with the Rayence’s 1417WCC or upgraded to premium with the NEW low dose GreenON DR system which is fully integrated with the generator controls and all DR and generator functions can be controlled from the large touch screen workstation display with the Xmaru V1 software.

Fully Integrated
Compact Design
Heavy Duty 6 Way Elevating Table

Recessed Foot-Pedals
Wall Stand Lowers to Below 10”
Cross Table Capability

The Elevating 6 Way Heavy Duty, all-steel table features a quiet
lift and a capacity of 650 lbs
There is also an option to order the system with an 84”x30.5”
tabletop and 4 way lock release

The 4 recessed foot pedal design simplifies
patient positioning eases accessibility, and
locking of tabletop movement. The collision
protection electronics and fail-safe locks ensure
safe operation

The ergonomic tube stand
handles are designed for
ease of positioning. Cross
table exams are easily
performed using the +/-
180 degree rotational and
+/- 5” transverse
positioning capability

The wall stand has quick-grip
release hand control for easy
positioning of the wall receptor
and side-mounted handgrip
bars stabilize the patient during
PA exams. (Optional overhead
patient handgrips help stabilize
patients for lateral views)

The long vertical travel of both
the wall stand and tube arm
facilitate a full range of exams
including weight-bearing
studies and the ergonomically
designed handle allows for easy
positioning of the wall stand
receptor

Specifications

DETECTOR

Model



TUBE STAND

Style
Rail length
Transverse travel
Long Travel of Focal Spot
Display


Wall to focal spot at detent position
Tube Rotation

WALL STAND

Model
Vertical Travel Range
Left or Right Hand Load Bucky



TUBE

Model
Tube Focal Spot



COLLIMATOR

Model
Style
Features

GENERATOR

Generator Power Output
mA range
Power
mAs range



TABLE

Model
Movement
Vertical travel
Transverse/Long Travel
Dimensions
Grid

OPTION

Option
Table travel
Transverse travel
Longitudinal travel
Weight Capacity



ROOM

Min. Required

1417WCC / GreenON 1417(Premium)



floor mounted
10 ft rail
9.75" travel
96"
angulation dial, handgrips, electric locks
Vertical Travel Range 14.56" - 72.44"
43.0"platform, 44.13" trunnion
180 degrees, 90 degree detents



J1000
15" min, 70" max
yes



E411
.6-1.5 focal, 200 KHU



5658
LED , 150kVp w/ swivel mount
laser bucky light and tape measure



 421/3e, 42kW high freq
25-500mA
205/250-1 phase 208/408-3 phase
0.1-600mAs



S222
6 way elevating table
23-34"
10" transverse, 30" longitudinal
84x30", 74" table top option
103L, 10:1, 34-44"FD



downgrade to S223 4 way table
84x30", 51" long enclosed welded pedestal
plus or minus 5"
30"
400 lbs



 12'6" x 11' x 9

* Specifications subject to change without prior notice *


Harmonic Stitching

(optional)

Image stitching is achieved by selecting one of three methods: Full-Auto, Semi-Auto or Manual. To eliminate the exposure borders of each image due to varying densities, Rayence’s advanced gradation process is automatically applied. Together with Rayence’s optional automatic stitching software, up to three views can be automatically stitched at a touch of a button, making stitching examinations easier than ever to attain.

System Requirement

Monitor Resolution


CPU
Memory




Operation System

1,280 x 768 (Minimum) 1,680 x 1,050 1,920 x 1,080 (Optimized)
 Intel Core™ i5 or more
Intel GMA 950 or more Intel GMA X3500 or more Nvidia Geforce FX5200 or more 512MB or more (No Shared Memory)
Windows 7 (32bit/64bit) Professional or Home Edition Window 8 (32bit/64bit) Professional or Enterprise

* Specifications subject to change without prior notice *



Flex-Rad

Flexible Multi-Purpose X-ray Room

Flex-Rad

Multi-Purpose Floor Rail Radiographic System

The Flex-Rad is a unique flexible full-featured multi-purpose radiographic room that comes standard with the Rayence 1717SCC DR system which is fully integrated with the generator controls and all DR and generator functions can be controlled from the large touch screen workstation display

Fully Integrated
Tilting Motorized Elevating Bucky

Manual Counter Balanced X-Ray Tube Movement

Collision Sensing and Power Disrupt
Locking Wheels Mobile Table
Flexible for Multiple Exam Views

The manual drive tube stand
easily moves along the 8 ft rail
and its traditional design
simplifies the learning curve as
it offers all of the standard
features of a standard tube arm

The motorized
detector stand which
takes the place of
the wall stand can be
tilted in a variety of
angles to get any
view

The heavy-duty mobile table can be
used when needed and can support
up to 500 lbs

There is virtually any view
possible and only limited by
the users’ imagination

Specifications

DETECTOR

Model



TUBE STAND

Style
Rail length
Transverse travel
Long Travel of Focal Spot
Display



Vertical Travel Range
Wall to focal spot at detent position



Tube Rotation

WALL STAND

Model
Left or Right Hand Load Bucky

Grid



TUBE

Model
Tube Focal Spot



COLLIMATOR

Model
Style
Features

GENERATOR

Generator Power Output
mA range
Power
mAs range



TABLE

Model
Movement
Vertical travel
Dimensions

Weight rating

ROOM

Min. Required

1717SCC



floor mount
8 ft or 10 ft
95.5" or 7.95 ft
72"
angulation dial, operator handgrips, electronic positioning locks
59"
6" trunnion tube mount with

cooling fan for x-ray tube
135 degrees +/-



SST-3001
left hand load
10:1, 103 line , 54" focus grid



E411
0.6-1.5mm focal spot, 200 KHU



5658
LED , 150kVp w/ swivel mount
laser bucky light and tape measure



421/3e, 42kW high freq
25-500mA
205/250-1 phase 208/408-3 phase
0.1-600mAs



ST1000 option
mobile table(non elevating)
fixed 27.5"
30"x80"
500 lb



13' x 11' x 9

* Specifications subject to change without prior notice *



XMARU VIEW V1

Acquisition Software

Xmaru View V1

SMART MEDICAL DIGITAL IMAGING SOLUTIONS

XmaruView is a flexible image acquisition software for today’s diagnostic imaging providers. The XmaruView (XV) console drives the Xmaru Panel Series to its full potential using industry’s most advanced image processing algorithms for the highest quality diagnostic images.

The XV software comes with standard features like DICOM Modality Work List (MWL), Image Stitching, DICOM Printing, and DVD/CD Burning with viewer.

An important feature offered with the XmaruView is Analysis Statistic Report (ASR). The Analysis Statistics Report keeps track of your image acceptance, rejections, retakes and deletion rates. With the assistance of industry professionals, the XV software optimizes workflow with an easy to navigate GUI.

Tapered, Recessed Edges

Magnetic Battery Charger

IP 66 Water Resistant

Image Storage up to 200 Images
Room Sharing Functionality
Auto Triggering Technology

Harmonic Stitching

Intuitive GUI

Intuitive and Direct Graphic User



Interface with X-ray Detector and Generator


Optimized Exposure Conditions and Image Review


Reducing Unnecessary Rework and Test
