RADIOGRAPHY

SOLUTIONS

Hospitals and Imaging Centers

Both hospitals and imaging Centers demand the best, and Rayence provides hospital-grade quality x-ray rooms as well as DR systems that can provide excellent image quality and smooth integration into the daily workflow and information transmission within the facility. Our XR-5 and Flex-Rad X-ray systems are made to meet the demand and offer two excellent choices that can meet any requirement.

Our low dose line of high-resolution cesium DR panels come with DICOM protocols standard and in a variety of sizes ranging from 10 x 12 to 17 x 17, all are Cesium and come with DICOM protocols. Our user software facilitates patient workflow and transmission of exam images to point of need.

Menu

Universal Radiography Systems

XR5

Flex-Rad



1012WCC/WGC

10x12 Wireless Flat Panel Detector

WIRELESS TECHNOLOGY IN COMPACT DESIGN

The ergonomically designed C-Series Cesium Iodide and Gadolinium Oxysulfide wireless detectors are designed to offer new levels of handling, functionality and exceptional diagnostic image quality in the X-ray room and beyond.

The compact and lightweight Xmaru 1012 Wireless Digital Flat Panel Detectors are well designed to satisfy the daily diagnostic needs of the most demanding user.

Tapered, Recessed Edges

Thin and Lightweight Design
Optional Portable Battery Charger

Image Storage Up To 200 Images
Room Sharing Functionality
Auto Triggering Technology

Superb Image Quality

The detector's high Detector Quantum Efficiency (DQE) achieves superb image quality with low patient dose.

Durability

Supporting up to 660 lbs, the detector is manufactured with a shock, vibration, and scratch-resistant carbon fiber composition.

Water Resistant (IP 66)

The detector is water-resistant to most typical water spills in a hospital as well as in outdoor applicants.

Specifications

Active Area
Scintillator
Resolution
Effective Pixel Matrix
Pixel Pitch
A/D Conversion
Preview Time
Operation Environment




Energy Range
Data Output
Weight
Dimensions

12.7 x 10.4 inch
 Cesium (1210WCC)/Gadox (1210WGC)
 3.9 lp/mm
  2520 x 2008
 127 ㎛
 14/16 bit
 ≤ 5 Sec.
 Temperature. +5 ~ +40°F
Humidity. 30 ~ 75%
Pressure. 70 ~ 106 kPa
 40~150 kVp
  Ethernet 1 Gbps Ethernet
   5.5 lbs / 2.5 kg
  12.9 x 10.6 x 0.6 in

* Specifications subject to change without prior notice *



1417WCC/WGC

14x17 Wireless DR Flat Panel Detector

PROVIDING PATIENT THROUGHPUT IN YOUR HOSPITAL AND BEYOND

The ergonomically designed C-Series Cesium Iodide and Gadolinium Oxysulfide wireless detectors are designed to offer new levels of handling, functionality and exceptional diagnostic image quality in the X-ray room and beyond.

The compact and lightweight Xmaru 1417 Wireless Digital Flat Panel Detectors are well designed to satisfy the daily diagnostic needs of the most demanding user.

DICOM File Management and Printing
Image Magnification
Image Stitching

CD recording with CD viewer
Measuring the Length and Angles of the Image
Adding Annotation Text, Graphics and Electronic Markers to an Image

Superb Image Quality

The detector's high Detector Quantum Efficiency (DQE) achieves superb image quality with low patient dose.

Durability

Supporting up to 660 lbs, the detector is manufactured with a shock, vibration, and scratch-resistant carbon fiber composition.

Water Resistant (IP 66)

The detector is water-resistant to most typical water spills in a hospital as well as in outdoor applicants.

Specifications

Active Area
Scintillator
Resolution
Effective Pixel Matrix
Pixel Pitch
A/D Conversion
Preview Time
Operation Environment




Energy Range
Data Output
Weight
Dimensions

  16.7 x 14 inch
 Cesium (1417WCC)/Gadox (1417WGC)
  3.5 lp/mm
   3268 x 2756
  140 ㎛
 14/16 bit
  ≤ 5 Sec.
 Temperature. +5 ~ +40°F
Humidity. 30 ~ 75%
Pressure. 70 ~ 106 kPa
  40~150 kVp
  Ethernet 1 Gbps Ethernet
  6.6 lbs / 3 kg
 18.1 x 15.1 x 0.6 in

* Specifications subject to change without prior notice *



1717WCC/WGC

17x17 Wireless Flat Panel Detector

PROVIDING PATIENT THROUGHPUT IN YOUR HOSPITAL AND BEYOND

The new, ergonomically designed C-Series Cesium Iodide and Gadolinium Oxysulfide wireless detectors are designed to offer new levels of handling, functionality and exceptional diagnostic image quality in the x-ray room and portable applications. Carbon-fiber, seamless unibody construction combined with a shock, vibration and scratch resistant composition makes them well-suited for demanding imaging environments.

Tapered, Recessed Edges

Magnetic Battery Charger

IP 66 Water Resistant

Image Storage up to 200 Images
Room Sharing Functionality
Auto Triggering Technology

Optional Portable Battery Charger

A slim portable battery charger.

Specifications

Detection Area
Sensor Type
Scintillator
Pixel Matrix
Pixel Pitch
A/D Conversion
Resolution
Preview Time
Energy Range
Battery Operating Time
Weight
Dimensions

   17 x 17 inch
  Amorphous Silicon with TFT
 Cesium (1717WCC)/Gadox (1717WGC)
 3268 x 3268
 140 ㎛
 14/16 bit
  Max. 3.5 lp/mm
 ≤ 2 Sec.
 40~150 kVp
 Typ. 4 hrs
  7.7 lbs (including battery)
 18.1 x 18.1 x 0.6 in

* Specifications subject to change without prior notice *



1717SCC/SGC

17x17 Tethered Flat Panel Detector

UNIVERSAL AND AFFORDABLE SOLUTION WITH LARGE COVERAGE

The 1717SGC/SCC is designed to provide a larger imaging area while eliminating the need to rotate the detector to capture even the widest chest or abdomen.

The detector possesses the thickness of traditional ISO 4090 film cassettes, which makes retrofitting them into standard cassette trays easy. The use of 17x17 inch detector provides more flexibility when positioning anatomy and eliminates the need to be rotated for certain.

The 1717 S-Series is constructed with Rayence's auto-trigger signal sensing technology, removing the need for generator integration. Efficiency is improved by streamlining workflow through the elimination of the additional steps required when using film or CR.

Together with an image preview time of less than 5 seconds, patient throughput and overall productivity is increased, and the wait time for patients is decreased, providing an economical and ideal solution for any X-ray room.

Auto-Trigger Signal Sensing Technology
17x17 inch Active Area
Ideal for Table and Upright Wall Stands

Lightweight and Thin Dimensions
Ideal CR Cassette Repalcement.
140㎛ Pixel Pitch

Specifications

Detection Area
Sensor Type
Scintillator
Pixel Matrix
Pixel Pitch
A/D Conversion
Resolution
Preview Time
Energy Range
Data Output
Weight
Dimensions

 17 x 17 inch
 Amorphous Silicon with TFT
  Cesium (1717SCC) / Gadox (1717SGC)
3328 x 3328
140㎛
14/16 bit
Max. 3.5lp/mm
  ≤ 2Sec.
  40~150kVp
   Ethernet 1Gbps
 9.25lbs / 4.2kg
 18.1 x 18.1 x 0.6in

* Specifications subject to change without prior notice *



XR5

Digital Radiography Table

Versatile Full Featured Heavy Duty Radiographic Room

The XR5 is a full-featured radiographic room that comes standard with the Rayence 1417WCC DR system which is fully integrated with the generator controls and all DR and generator functions can be controlled from the large touch screen workstation display.

Fully Integrated
Compact Design
Heavy Duty 6 Way Elevating Table

Recessed Foot-Pedals
Wall Stand Lowers to Below 10”
Cross Table Capability

The Elevating 6 Way Heavy Duty, all-steel table features a quiet
lift and a capacity of 650 lbs
There is also an option to order the system with an 84”x30.5”
tabletop and 4 way lock release

The long vertical travel of both
the wall stand and tube arm
facilitate a full range of exams
including weight-bearing
studies and the ergonomically
designed handle allows for easy
positioning of the wall stand
receptor

The 4 recessed foot pedal design simplifies
patient positioning eases accessibility, and
locking of tabletop movement. The collision
protection electronics and fail-safe locks ensure
safe operation

The ergonomic tube stand
handles are designed for
ease of positioning. Cross
table exams are easily
performed using the +/-
180 degree rotational and
+/- 5” transverse
positioning capability

The wall stand has quick-grip
release hand control for easy
positioning of the wall receptor
and side-mounted handgrip
bars stabilize the patient during
PA exams. (Optional overhead
patient handgrips help stabilize
patients for lateral views)

Specifications

DETECTOR

Model



TUBE STAND

Style
Rail length
Transverse travel
Long Travel of Focal Spot
Display


Wall to focal spot at detent position
Tube Rotation

WALL STAND

Model
Vertical Travel Range
Left or Right Hand Load Bucky



TUBE

Model
Tube Focal Spot



COLLIMATOR

Model
Style
Features

GENERATOR

Generator Power Output
mA range
Power
mAs range



TABLE

Model
Movement
Vertical travel
Transverse/Long Travel
Dimensions
Grid

OPTION

Option
Table travel
Transverse travel
Longitudinal travel
Weight Capacity



ROOM

Min. Required

1417WCC



floor mounted
 10 ft rail
 9.75" travel
96"
angulation dial, handgrips, electric locks
Vertical Travel Range 14.56" - 72.44"
 43.0"platform, 44.13" trunnion
 180 degrees, 90 degree detents



J1000
15" min, 70" max
 yes



E411
 .6-1.5 focal, 200 KHU



5658
LED , 150kVp w/ swivel mount
laser bucky light and tape measure



 421/3e, 42kW high freq
 25-500mA
205/250-1 phase 208/408-3 phase
 0.1-600mAs



S222
6 way elevating table
 23-34"
 10" transverse, 30" longitudinal
84x30", 74" table top option
103L, 10:1, 34-44"FD



downgrade to S223 4 way table
 84x30", 51" long enclosed welded pedestal
 plus or minus 5"
 30"
 400 lbs



 12'6" x 11' x 9

* Specifications subject to change without prior notice *



Flex-Rad

Flexible Multi-Purpose X-ray Room

Multi-Purpose Floor Rail Radiographic System

The Flex-Rad is a unique flexible full-featured multi-purpose radiographic room that comes standard with the Rayence 1717SCC DR system which is fully integrated with the generator controls and all DR and generator functions can be controlled from the large touch screen workstation display

Fully Integrated
Tilting Motorized Elevating Bucky

Manual Counter Balanced X-Ray Tube Movement

Collision Sensing and Power Disrupt
Locking Wheels Mobile Table
Flexible for Multiple Exam Views

The manual drive tube stand
easily moves along the 8 ft rail
and its traditional design
simplifies the learning curve as
it offers all of the standard
features of a standard tube arm

The motorized
detector stand which
takes the place of
the wall stand can be
tilted in a variety of
angles to get any
view

The heavy-duty mobile table can be
used when needed and can support
up to 500 lbs

There is virtually any view
possible and only limited by
the users’ imagination

Specifications

DETECTOR

Model



TUBE STAND

Style
Rail length
Transverse travel
Long Travel of Focal Spot
Display



Vertical Travel Range
Wall to focal spot at detent position



Tube Rotation

WALL STAND

Model
Left or Right Hand Load Bucky

Grid



TUBE

Model
Tube Focal Spot



COLLIMATOR

Model
Style
Features

GENERATOR

Generator Power Output
mA range
Power
mAs range



TABLE

Model
Movement
Vertical travel
Dimensions

Weight rating

ROOM

Min. Required

1717SCC



floor mount
8 ft or 10 ft
95.5" or 7.95 ft
72"
angulation dial, operator handgrips, electronic positioning locks
59"
6" trunnion tube mount with

cooling fan for x-ray tube
135 degrees +/-



SST-3001
left hand load
10:1, 103 line , 54" focus grid



E411
0.6-1.5mm focal spot, 200 KHU



5658
LED , 150kVp w/ swivel mount
laser bucky light and tape measure



421/3e, 42kW high freq
25-500mA
205/250-1 phase 208/408-3 phase
0.1-600mAs



ST1000 option
mobile table(non elevating)
fixed 27.5"
30"x80"
500 lb



13' x 11' x 9

* Specifications subject to change without prior notice *
